Description
The DEKS Vela A15 Edge Slot Drain is a sleek, discreet drainage solution designed for modern patios, paved areas, pathways and landscaped spaces. With its slim stainless-steel slot and flush-finish styling, it’s the ideal choice where you want effective drainage without visible grating.
Built around a strong polypropylene (PP) channel and certified to A15 load class, the Vela Edge Slot system is suitable for all pedestrian areas around the home or garden. It offers full flexibility through a choice of two channel depths (50mm or 84mm) and two upstand heights (20mm or 87mm), making it compatible with porcelain paving, stone, slabs, and a wide range of build-ups.
Installation is fast and straightforward, with a modular 1m length and a design that allows inspection chambers and outlets to be located exactly where needed, reducing waste and improving workflow.
Key Benefits
• Discreet slot drain design for clean, contemporary finishes
• Available in 50mm (shallow) or 84mm (standard) channel depths
• Choice of 20mm or 87mm stainless-steel upstands to suit different paving build heights
• A15 load class – perfect for pedestrian areas, patios and garden spaces
• Lightweight, durable polypropylene channel body
• Heel-safe slot design with smooth water flow
• Modular 1m sections for flexible, low-waste installation
• Fully compatible with the DEKS Vela A15 accessories (end caps, outlets, sumps)
• Ideal for porcelain paving, natural stone and block paving
Product Specifications
• Channel Length: 1000mm
• Channel Width: 121mm
• Depth Options: 50mm or 84mm
• Upstand Options: 20mm or 87mm
• Load Rating: A15 (EN1433 – pedestrian use)
• Channel Material: Polypropylene (PP)
• Slot Edge Material: Stainless steel
• Applications: Patios, walkways, thresholds, garden paving, landscaping
