Description
The Alusthetic Low Profile Threshold Drain Connector is designed to securely join two low profile threshold drain channels, ensuring a strong, stable, and watertight connection. Manufactured from robust extruded PVC, it provides a discreet, flush-fit join that maintains the sleek finish of the Alusthetic drainage system.
With a depth of 60mm and width of 65mm, this connector is purpose-made for the Low Profile Alusthetic Threshold Drain and Grate system. Its simple push-fit installation allows for quick assembly, and for a fully watertight seal, the connector can be fixed in place using a PVC solvent weld.
Like the rest of the Alusthetic range, this component is UKCA & CE marked and fully certified to Load Class A15 (BS EN 1433:2002). It can withstand up to 15kN in soft ground and around 25kN in concrete, making it ideal for domestic projects such as patios, pathways, thresholds, and other non-trafficked areas.
Features & Benefits:
• Provides a strong and secure connection between two low profile channels
• Slim, discreet design for a flush, seamless join
• Manufactured from durable extruded PVC
• Quick and easy to install – solvent weld compatible for a watertight finish
• Certified to Load Class A15 (BS EN 1433:2002)
• Withstands up to 15kN (soft ground) and 25kN (concrete)
• Ideal for thresholds, patios, walkways, and garden areas
• Fully UKCA & CE marked for compliance and reliability
Product Specifications:
• Material: PVC
• Compatible Channel Size: 65mm (W) x 60mm (D) x 1000mm (L)
• Load Rating: A15 – 15kN (soft ground), 25kN (concrete)
• Certification: UKCA & CE marked
